X6 · 2008–2014
BMW X6 (E71) wheels
xDrive35i · xDrive50i · X6 M
Bolt pattern5x120
Hub bore74.1 mm
Lug boltsM14x1.25
Wheel diameter19–22"
Factory front9" ET48
Factory rear10" ET40
Flush front10" ET40
Flush rear11" ET37
Front width range8.5–10.5"
Rear width range9–11.5"
Staggered setsYes
Clearance limits used for grading — front: outer lip ≤ 90 mm, inner lip ≤ 175 mm from the hub face; rear: ≤ 106 / 185 mm.
- This chassis has a 74.1 mm hub. Wheels bored 72.6 mm will not fit without machining.
- xDrive: front and rear tires must have matching rolling diameters (within ~1%).
